Nombre de la marca: Fosi Audio
Producto químico de alta preocupación: Ninguno
Potencia máxima por canal: Sin energía
Paquete: Sí
Canales: 2 (2.0)
Certificación: CE
Número de modelo: Q4
Input: USB, OPT, COA
Output: RCA, 3.5mm Headphone Jack
Work Voltage: DC 5V
Amp Output Maximum Power: 125mW/32Ohm
DAC Chippest: MS8412
USB Chippest: SA9023
Headphone Chippest: 97220
OPM Chippest: NE5532
frequency response: 20 Hz - 20 kHz
distortion rate: 0.01%
Supported Headphone Impedance: 16?-200?
Features:
Easy to set up, no special software, app, or driver to install, a true plug-and-play digital audio adapter.
You will get neutral sound when you adjust the EQ to 12 o'clock position.
With USB, optical and coaxial S/PDIF inputs can fit with most home audio system, and RCA output can be connected to amplifier or powered speakers on your desktop; Built-in Hi-Fi headphone amp chip can drive most 16ohm to 200ohm headphones
160mW RMS(32 ohms, 20 Hz - 20 KHz, 0.01% THD), with bass and treble control can be used as preamp or volume controller for your PC/MAC/Computer
Mini Compact D/A converter, stream bit-perfect 24bit/192KHz HD with low jitter, with output protect circuit, safe for your expensive audio system
We offer 24-month warranty, and friendly customer service!
Highlight:
Model: Q4
Color: Black
DAC Chippest : MS8412
USB Chippest: SA9023
Headphone Chippest : 97220
OPM Chippest: NE5532
PC-USB supports input sampling rate: 96K/24Bit
High and low sound adjustment range: ±6dB
Fiber/coaxial support input sampling rate: 192K/24Bit
Frequency response: 20Hz-20kHz (±3dB)
PC-USB support operating system: XP/W7/W8/W10/MAC/linux
Distortion: 0.01%; SNR: ?105dB
Amp output maximum power: 125mW 32? load
Headphone matching impedance: 16-200?
Working voltage: DC5V; RCA output level: 2.3V
Size (L*W*H): 73.5*98*33MM (without knobs and terminals)
Package Include:
*1x Fosi Audio DAC-Q4
*1x 5V USB Power Supply Cable
*1x PC-USB Cable
*1x Optical Cable
*1x User’s Manual
